Description
| Specifications & Details | |||
|---|---|---|---|
|
Tractor Capability |
20-30HP |
40-50 HP |
60-85 HP |
|
Size |
7.5’*x5’x1.5’ |
11’x6.5’x2.25’ |
11’x7’x2.25′ |
|
Bed Sheet Gauge |
SWG12 |
SWG12 |
SWG12 |
|
Side Sheet Gauge |
SWG12 |
SWG12 |
SWG12 |
|
Axle Size |
4-1/2” x 3/8” |
4-1/2″ X 3/8” |
4-1/2” x 3/8” |
|
Frame Channel Size |
7” x 3” |
7” x 3” |
7” x 3” |
|
Tyre Size |
7.50-10 |
9.00-16 or 8.25-20 |
8.25-20 |
|
Number of Tyres |
2 |
2 |
4 |
|
Weight (w/o load) |
700Kg |
1000Kg |
1 400Kg |
|
Lift Capacity |
3.5 ton |
5 ton |
8 – 10 ton |
Types of Agricultural Trailers
There are several different types of agricultural trailers available on the market. Some common types include:
Flatbed trailers: These trailers have a flat, open bed, making them ideal for transporting large, irregularly shaped items. They can be fitted with sides or a canopy for added protection.
Box trailers: As the name suggests, these trailers have a box-like structure, making them ideal for transporting smaller, more delicate items. They are typically enclosed and can be fitted with shelving or other storage solutions.
Tipping trailers : These trailers have a hydraulic mechanism that allows them to be tilted, making it easy to unload materials. They are often used for transporting sand, gravel, and other bulk materials.
Tank trailers: These trailers are designed to transport liquids, such as water or fuel. They are fitted with tanks and pumps, making it easy to transfer the liquid to other containers or equipment.
How to Use Agricultural Trailers
Using an agricultural trailer is relatively straightforward. First, you will need to attach the trailer to your tractor. This can typically be done by attaching the trailer to the tractor’s rear drawbar or hitch. Make sure everything is securely fastened before proceeding.
Next, you will need to load the trailer with your equipment or materials. Depending on the type of trailer you are using, this may involve using a forklift or other equipment to load the materials onto the trailer. Again, make sure everything is securely fastened before towing the trailer.
Finally, you can start towing the trailer. Make sure to follow all safety guidelines and regulations when towing, such as maintaining a safe speed and using proper signaling.
Conclusion
Agricultural trailers are an essential tool for any farmer or agricultural business. They make it easy to transport equipment, supplies, and other materials around the property or to other locations. Whether you need a flatbed trailer, box trailer, tipping trailer, or tank trailer, there is an agricultural trailer out there to meet your needs.
