Description
New Holland Ghazi Tractor Specifications
New Holland 65 HP Specifications
Performance & Weight
| Engine power at flywheel | 65 HP |
|---|---|
| Operating weight | 1,785 kg |
Engine
| Engine model | New Holland 8035.05 |
|---|---|
| Type | 4-stroke, direct injection diesel |
| Number of cylinders | 3 |
| Bore × stroke | 104 × 115 mm |
| Displacement | 2,931 cc |
| Compression ratio | 17:1 |
| Maximum torque at 1,500 rpm | 23.9 kgm |
| Cylinder liners | Dry type |
| Cooling | Water cooling system |
| Radiator | Five-row brass tube and fin |
| Lubrication | Forced-feed system |
| Fuel injection pump | Distributor type with mechanical speed governor |
| Exhaust | Vertical exhaust muffler |
Filters
| Air filter | Oil bath with pre-cleaner |
|---|---|
| Fuel filter | 2 replaceable cartridges |
| Oil filter | Easy-to-change, continuous-flow cartridge |
Clutch
| Type | Dual plate, dry type |
|---|---|
| Controls | Separate transmission pedal and PTO hand lever |
| Plate diameter | 11 inches |
| Plate facing | Asbestos compound, as listed in the supplied sheet |
Transmission
| Gearbox | Constant-mesh gears |
|---|---|
| Number of gears | 8 forward, 2 reverse |
| Synchromesh | 3rd, 4th, 7th and 8th speeds |
| Differential lock | Pedal actuated with automatic disconnection |
| Final drives | Single-reduction spur gears |
| Starter safety switch | Gearbox mounted |
Track Adjustment
| Front track — 8 positions | 1,320 / 1,420 / 1,520 / 1,620 / 1,720 / 1,820 / 1,920 / 2,020 mm |
|---|---|
| Rear track — 8 positions | 1,200 / 1,300 / 1,400 / 1,500 / 1,600 / 1,700 / 1,800 / 1,900 mm |
Steering
| Type | Hydro-assisted power steering with independent circuit |
|---|---|
| Turning radius with brakes | 3,400 mm |
| Turning radius without brakes | 3,900 mm |
Power Take-Off
| Type | Fully independent |
|---|---|
| PTO speed | 540 rpm at 2,160 engine rpm |
| Shaft diameter | 35 mm / 1⅜ inches |
| Number of splines | 6 |
| High-speed drive | Same speed as engine, for high-speed implements |
| High-speed drive shaft diameter | 35 mm / 1⅜ inches |
Hydraulic Lift
| Controls | Draft and position control |
|---|---|
| Draft sensing | Through top link |
| Pump type | Gear type, driven by engine crankshaft |
| Pump capacity | 22.7 L/min |
| Relief valve opening pressure | 150–170 kg/cm² |
| 3-point linkage | Category I–II |
| Response control | Manual |
| Lower links | Interchangeable balls and sway restrictors |
| Control lever | With safety stop |
| Maximum lifting capacity | 1,450 kg with lower links horizontal |
Driver’s Seat & Fenders
| Seat | Deluxe seat with spring suspension, adjustable to the driver’s weight |
|---|---|
| Fenders | Flat top |
Capacities
| Fuel tank | 54 L |
|---|---|
| Engine oil | 8 L |
| Hydraulic transmission | 18 L |
| Rear axle | 2 L per side (4 L total) |
| Air cleaner | 1 L |
| Power steering | 1.5 L |
Brakes
| Service brakes | Dry band type with mechanical control |
|---|---|
| Parking brake | Hand lever operated |
Tyres
| Front | 6.00-16 |
|---|---|
| Rear | 14.9/13-28 |
Body
| Hood | Side-hinged cover for engine inspection |
|---|---|
| Front grille | Removable for quick access to the air cleaner and battery |
Lighting System
| Headlights | Low and high beam with 3-position halogen headlamps |
|---|---|
| Additional lighting | Direction indicators, parking and hazard lights |
| Dashboard indicators | Blue high-beam warning light and low oil pressure warning light |
Electrical System
| Starting system | 12 V |
|---|---|
| Starter motor | 3.35 HP (2.5 kW) |
| Alternator | 400 W |
| Battery | 100 Ah |
| Starting aid | Included |
Front Axle
| Type | Telescopic, inverted U |
|---|---|
| Tread | Variable |
AECO Tractors is providing this heavy duty tractor directly manufactured from Al Ghazi Tractors in Pakistan.
TRACTOR OPTIONAL EQUIPMENT
AECO offer optional tractor equipment like Roll-over Protections System (ROPS), Mirrors Front and Rear, Pintle Hooks, Front Weights, Nine-Hole Drawbars, Power take-off pulleys (PTO), Trailer Hooks, Fiber-Glass Canopies and Hydraulic Valves
