Description
Massey Ferguson 375 4WD Tractor Specifications
Massey Ferguson 375 4WD Specifications
Performance
| Engine power at 2,200 rpm | 75 (B.S.) hp* |
|---|---|
| Torque at 1,400 engine rpm | 276 Nm |
| PTO power at rated engine speed | 66 hp** |
*Certified to BS AU 141a: (1971).
**Manufacturer’s estimate.
Engine
| Type | Diesel / 4.41 |
|---|---|
| Number of cylinders | 4 |
| Injection | Direct |
| Bore | 101 mm |
| Stroke | 127 mm |
| Capacity | 4.1 litres |
| Aspiration | Natural |
| Compression ratio | 15.3:1 |
| Starting aid | Thermostart |
| Throttle control | Hand and foot |
| Cooling | Water |
| Air cleaner type | Oil bath |
| Air pre-cleaner | Over bonnet, air swirl |
| Fuel filter | Dual, high capacity |
| Exhaust | Vertical muffler under bonnet |
| Oil cooler | Water cooled |
| Oil drain plug | Magnetic |
Electrics
| Voltage | 12 V, negative earth |
|---|---|
| Battery | 88 Ah, maintenance free |
| Alternator | 34 A |
| Starter motor | 2.2 kW |
Clutch
| Type | Dual (damper) |
|---|---|
| Diameter | 305 × 254 mm |
| Lining material | Cerametallic |
Transmission
| Type | Sliding spur |
|---|---|
| Number of gears | 8 forward, 2 reverse |
Road speeds at 2,200 engine rpm with 16.9/14-30 tyres.
| Gear | Speed (km/h) |
|---|---|
| Forward 1 (first low) | 2.7 |
| Forward 2 | 3.9 |
| Forward 3 | 5.3 |
| Forward 4 | 7.1 |
| Forward 5 (first high) | 10.8 |
| Forward 6 | 15.6 |
| Forward 7 | 21.3 |
| Forward 8 | 28.6 |
| Reverse 1 (low) | 3.6 |
| Reverse 2 (high) | 14.5 |
Power Take-Off
| Type | Live |
|---|---|
| Engine speed at 540 PTO rpm | 1,789 rpm |
| Shaft diameter | 35 mm |
| Number of splines | 6 |
Hydraulics
| Functions | Draft control, position control, response control and constant pumping |
|---|---|
| Pump type | Reciprocating Ferguson pump |
| Oil flow | 16.7 L/min |
| Pressure | 21.2 MPa at normal operating temperature |
| Lift capacity at lower link ends | 2,145 kg with lower links horizontal |
| Lower links | Category I & II interchangeable balls; adjustable heavy-duty yoke tubes |
Steering
| Type | Hydrostatic |
|---|
Front Axle
| Drivetrain | 4WD |
|---|---|
| Type | Heavy-duty box section, adjustable |
Rear Axle & Brakes
| Axle type | Straddle with epicyclic reduction unit |
|---|---|
| Brake pedal | Pendant |
| Brake type | Oil immersed, multi-disc |
| Braking area | 1,774 cm² |
| Brake actuation | Hydraulic |
| Parking brake | Hand lever operated |
| Differential lock | Mechanical |
Instrumentation
| Gauges | Tachometer, hourmeter, fuel level, water temperature and battery condition |
|---|---|
| Warning lights | Direction indicator, electric charge, headlight main beam and low engine oil pressure indication |
Tyres
| Front | 11.2-24 |
|---|---|
| Rear | 16.9/14-30 |
Track Adjustment
| Front axle | 1,673–2,205 mm |
|---|---|
| Rear axle | 1,848–2,250 mm |
Weight & Dimensions
Approximate figures with 11.2-24 front and 16.9/14-30 rear wheels, with full fuel, oil and water.
| Gross weight | 2,895 kg |
|---|---|
| Overall length | 3,810 mm |
| Overall width | 1,965 mm |
| Wheelbase | 2,260 mm |
| Height over exhaust | 2,660 mm |
| Height over steering wheel | 1,700 mm |
| Turning circle without brakes | 9,360 mm |
| Ground clearance under engine sump | 450 mm |
Capacities
| Fuel tank | 108.0 L |
|---|---|
| Engine sump | 7.5 L |
| Cooling capacity | 16 L |
| Hydraulic system | 42 L |
| Power steering reservoir | 2.0 L |
| Oil bath air cleaner | 0.75 L |
| Brake oil | 0.25 L |
| 4WD front axle differential | 6.5 L |
| Hub, each side | 0.75 L |
Standard Equipment
Weight frame, standard toolbox with set of tools, top link, USB port, top link end Category I & II balls, check chains, stabiliser chains, spring suspension seat, flat top fenders, operator’s and service manual, and wider heat shield.
Optional Equipment
Swinging drawbar, front weights, pintle hook and 9-hole drawbar.
Operator Area
| Seat | Cushioned |
|---|---|
| Operator platform | Spacious |
| Fenders | Flat top |
| Tool | Standard |
Massey Ferguson 375 4WD Tractor For Sale
The Massey Ferguson 375 4WD tractor stands as a testament to power, efficiency, and reliability in agricultural machinery. In this detailed guide, we explore the specifications, features, pricing, and performance of the Massey Ferguson 375 4WD tractor, a true workhorse for farmers and agricultural professionals.
Massey Ferguson 375 Specifications
The Massey Ferguson 375 boasts impressive specifications that make it a preferred choice among farmers:
- Engine: Equipped with a robust 75 horsepower engine, the Massey Ferguson 375 delivers ample power for a wide range of agricultural tasks.
- Transmission: Featuring a smooth and efficient transmission system, this tractor ensures seamless gear shifting and optimal performance in varying terrain conditions.
- 4WD Capability: The 4WD capability of the Massey Ferguson 375 enhances traction and maneuverability, making it ideal for field work and challenging environments.
- Fuel Consumption: With its efficient fuel consumption, the Massey Ferguson 375 offers cost-effective operation without compromising on performance.
- Hydraulics: The tractor’s hydraulic system provides excellent lifting capacity and control, allowing operators to handle heavy implements with ease.
- Comfort and Safety: Designed with operator comfort and safety in mind, the Massey Ferguson 375 features ergonomic controls, a comfortable seating arrangement, and advanced safety features.
Massey Ferguson 375 Specs
- Engine Type: 4-cylinder diesel engine
- Horsepower: 75 HP
- Transmission: Multi-speed gearbox with forward and reverse gears
- Drive: 4WD (Four-Wheel Drive)
- Hydraulics: 2,145 KG lifting capacity
- PTO (Power Take-Off): Standard and optional PTO configurations available
- Weight: 3,011 KG (without attachments)
- Tires: Suitable for various terrain conditions
Massey Ferguson 375 Tractor Data
- Fuel Type: Diesel
- Cooling System: Liquid-cooled
- Brakes: Hydraulic wet disc brakes
- Steering: Power steering for enhanced maneuverability
Massey 75 HP Tractor Price and Availability
The Massey Ferguson 375 4WD tractor is competitively priced, offering exceptional value for its performance and features. For the latest pricing and availability, please contact authorized Massey Ferguson dealers or visit our website.
Massey Ferguson 375 Fuel Consumption
Thanks to its efficient engine design and advanced fuel management system, the Massey Ferguson 375 ensures optimal fuel consumption, reducing operational costs and environmental impact.
Massey Ferguson 375 Manual and Review
The Massey Ferguson 375 comes with a comprehensive operator’s manual that provides detailed information on maintenance, operation, and troubleshooting. Additionally, customer reviews and testimonials highlight the tractor’s reliability, durability, and performance in real-world farming conditions.
Massey Ferguson 375 Parts and Service
Authorized Massey Ferguson dealers offer genuine parts and professional service for the Massey Ferguson 375 tractor, ensuring optimal performance, reliability, and longevity.
The Massey Ferguson 375 4WD tractor combines power, efficiency, and versatility to meet the diverse needs of modern agriculture. With its robust design, advanced features, and competitive pricing, this tractor is a valuable asset for farmers looking to enhance productivity and profitability. Explore the Massey Ferguson 375 4WD tractor for sale today and experience the difference in agricultural machinery excellence. If you’re looking for a tractor that takes engine power one step up with 4WD Traction, then it is recommended that you check out our newly listed Massey Ferguson 385 4WD.
Frequently Asked Questions (FAQs) for the Massey Ferguson 375 4WD Tractor
The MF 375 4WD features a robust 75 hp engine, four-wheel drive for enhanced traction, and advanced hydraulic systems. Its specifications include power steering, a heavy-duty front axle, and efficient fuel management, making it ideal for challenging terrains and heavy agricultural tasks.
Equipped with 4WD capability, the Massey Ferguson 375 4WD provides superior traction and power distribution. This is essential for wet and uneven fields, ensuring that productivity remains high regardless of environmental conditions.
The MF 375 price varies depending on additional features and dealer location. However, Aeco Export Company ensures competitive pricing with exceptional after-sales support, making it a cost-effective choice for farmers worldwide.
The MF 375 4WD is available for sale at Aeco Export Company, which offers global shipping and extensive customer support to ensure that you receive your brand new tractor without hassle.
The Massey Ferguson 375 4WD stands out due to its 75 hp engine, 4×4 capabilities, and the reputation of Massey Ferguson for building durable and reliable machinery. It’s designed to handle more demanding agricultural tasks, making it a versatile and powerful asset for any farm.
