MASSEY FERGUSON 390 4WD TRACTOR SPECIFICATIONS
Massey Ferguson 390 4WD Specifications
Performance
| Engine power at 2,200 rpm | 90 (B.S.) hp* |
|---|---|
| Torque at 1,600 engine rpm | 330 Nm |
| PTO power at rated engine speed | 75 hp** |
*Certified to BS AU 141a: (1971).
**Manufacturer’s estimate.
Engine
| Type | Diesel / 1004T |
|---|---|
| Number of cylinders | 4 |
| Injection | Direct |
| Bore | 100 mm |
| Stroke | 127 mm |
| Capacity | 4 litres |
| Aspiration | Turbo |
| Compression ratio | 16.0:1 |
| Starting aid | Thermostart |
| Throttle control | Hand and foot |
| Cooling | Water |
| Air cleaner type | Dry paper element |
| Air pre-cleaner | Centrifugal, over the bonnet |
| Fuel filter | Dual, high capacity |
| Exhaust | Under bonnet with vertical stack pipe |
| Oil cooler | Water cooled |
| Oil drain plug | Magnetic |
Electrics
| Voltage | 12 V, negative earth |
|---|---|
| Battery | 88 Ah, maintenance free |
| Alternator | 45 A |
| Starter motor | 2.8 kW |
Clutch
| Type | Dual (damper) |
|---|---|
| Diameter | 305 × 254 mm |
| Lining material | Cerametallic |
Transmission
| Type | Sliding spur |
|---|---|
| Number of gears | 8 forward, 2 reverse |
Road speeds at 2,200 engine rpm with 18.4/15-30 tyres.
| Gear | Speed (km/h) |
|---|---|
| Forward 1 (first low) | 3.1 |
| Forward 2 | 4.6 |
| Forward 3 | 6.3 |
| Forward 4 | 8.4 |
| Forward 5 (first high) | 12.8 |
| Forward 6 | 18.7 |
| Forward 7 | 25.6 |
| Forward 8 | 34.3 |
| Reverse 1 (low) | 4.3 |
| Reverse 2 (high) | 17.4 |
Power Take-Off
| Type | Live |
|---|---|
| Engine speed at 540 PTO rpm | 1,789 rpm |
| Shaft diameter | 35 mm |
| Number of splines | 6 |
Hydraulics
| Functions | Draft control, position control, response control and constant pumping |
|---|---|
| Pump type | Reciprocating Ferguson pump |
| Oil flow | 16.7 L/min |
| Pressure | 21.2 MPa at normal operating temperature |
| Lift capacity at lower link ends | 2,529 kg with lower links horizontal |
| Lower links | Category II fixed balls, adjustable heavy-duty yoke tubes and heavy-duty links |
Steering
| Type | Hydrostatic |
|---|
Front Axle
| Drivetrain | 4WD |
|---|---|
| Type | Heavy-duty box section, adjustable |
Rear Axle & Brakes
| Axle type | Straddle with epicyclic reduction unit |
|---|---|
| Brake pedal | Pendant |
| Brake type | Oil immersed, multi-disc |
| Braking area | 1,774 cm² |
| Brake actuation | Hydraulic |
| Parking brake | Hand lever operated |
| Differential lock | Mechanical |
Instrumentation
| Multifunction dashboard | Tachometer, hourmeter, PTO rpm, fuel level and water temperature |
|---|---|
| Warning lights and accessories | Direction indicator, 4WD engagement, electric charge, differential lock, headlight high and low beam, low engine oil pressure, low fuel warning, PTO engagement and auxiliary socket |
Tyres
| Front | 14.9-24 |
|---|---|
| Rear | 18.4/15-30 |
Track Adjustment
| Front axle | 1,734–2,266 mm |
|---|---|
| Rear axle | 1,924–2,326 mm |
Weight & Dimensions
Approximate figures with 14.9-24 front and 18.4/15-30 rear wheels, with full fuel, oil and water.
| Gross weight | 3,125 kg |
|---|---|
| Overall length | 3,810 mm |
| Overall width | 2,020 mm |
| Wheelbase | 2,260 mm |
| Height over exhaust | 2,700 mm |
| Height over steering wheel | 1,725 mm |
| Turning circle without brakes | 9,680 mm |
| Ground clearance under engine sump | 450 mm |
Capacities
| Fuel tank | 108.0 L |
|---|---|
| Engine sump | 7.8 L |
| Cooling capacity | 16.9 L |
| Hydraulic system | 42 L |
| Power steering reservoir | 2 L |
| Brake oil | 0.25 L |
| 4WD front axle differential | 6.5 L |
| Hub, each side | 0.75 L |
Standard Equipment
Weight frame, sun canopy, standard toolbox with set of tools, top link, USB port, top link end Category I & II balls, check chains, stabiliser chains, spring suspension seat, flat top fenders, operator’s and service manual.
Optional Equipment
Swinging drawbar, front weights, pintle hook and 9-hole drawbar.
Operator Area
| Seat | Cushioned |
|---|---|
| Operator platform | Spacious |
| Fenders | Flat top |
| Tool | Standard |
Comprehensive Guide on the Massey Ferguson 390 4WD Tractor
The Massey Ferguson 390 4WD Tractor is a high-performance model designed to tackle demanding agricultural tasks with ease. Renowned for its durability, reliability, and exceptional performance, this tractor is a top choice for farmers seeking a powerful and efficient machine. This guide provides an in-depth look into the features, specifications, and advantages of the Massey Ferguson 390 4WD, offering a comprehensive understanding of why it stands out in the market.
Overview
The Massey Ferguson 390 4WD is engineered for versatility and efficiency, capable of handling a wide range of agricultural operations. Its robust build and advanced technology ensure superior traction and stability, even in challenging conditions. This tractor is powered by a 90 horsepower engine, delivering ample power for heavy-duty applications.
Engine and Performance
The heart of the Massey Ferguson 390 4WD is its powerful Perkins diesel engine. This 4.41-liter engine is known for its efficiency and environmental friendliness, providing a robust 90 horsepower at 2200 RPM. The engine’s torque peaks at 314 Nm at 1600 RPM, ensuring the tractor can handle heavy loads with ease.
Transmission and Hydraulics
The Massey Ferguson 390 4WD features a sliding spur transmission with 8 forward and 2 reverse gears, offering precise control over speed and power. The hydraulic system is equally impressive, featuring draft control, position control, and response control. With a maximum oil flow of 16.7 liters per minute and a lifting capacity of 2,145 kg, it ensures efficient operation of various implements.
Power Take-Off (PTO) System
The Massey Ferguson 390 4WD is equipped with a robust Power Take-Off (PTO) system, essential for driving various implements and attachments. The Massey Ferguson 390 Tractor PTO delivers 540 performance, ensuring sufficient power for a wide range of farming activities. The live PTO design allows for seamless engagement and disengagement of the PTO without interrupting the tractor’s operation. This feature is particularly useful when operating equipment like rotary tillers, mowers, and balers, which require continuous power. The PTO shaft has a standard 35mm diameter with 6 splines, making it compatible with most agricultural implements.
Design and Comfort
The Massey Ferguson 390 4WD is designed with operator comfort and ease of use in mind. Features like a comfortable seat, hydrostatic power steering, and intuitive controls contribute to a more enjoyable and less strenuous working experience. The tractor’s robust straddle rear axle and oil-immersed multi-disc brakes ensure stability and safety, even in difficult terrain.
Fuel Efficiency and Environmental Impact
The Massey Ferguson 390 4WD is designed to maximize fuel usage, reducing operational costs and minimizing environmental impact. It also meets stringent emission standards, ensuring that it is environmentally friendly while maintaining high performance levels.
Tires and Stability
The Massey Ferguson 390 4WD is equipped with large front (12.4/11-24) and rear (18.4/15-30) tires, providing excellent traction and stability. This makes it ideal for use in various terrains, including muddy and sandy conditions. The tractor’s four-wheel-drive capability further enhances its stability and traction, allowing it to perform efficiently even in challenging environments.
Practical Applications
The versatility of the Massey Ferguson 390 4WD makes it suitable for a wide range of agricultural applications, including plowing, tilling, and transporting heavy loads. Its powerful engine, combined with its advanced transmission and hydraulic systems, ensures that it can handle a variety of tasks with ease. You can check our range of compatible MF 390 implements as well.
Competitive Edge
When compared to other tractors in its class, the Massey Ferguson 390 4WD stands out due to its combination of power, efficiency, and reliability. Its advanced features, such as the robust engine and high-capacity hydraulics, provide a competitive edge, making it a preferred choice for farmers looking to maximize productivity and efficiency.
Conclusion
The Massey Ferguson 390 4WD is a powerful, reliable, and versatile machine that stands out in the agricultural sector. Its advanced features, robust build, and exceptional performance make it an ideal choice for modern farmers looking to enhance their productivity and efficiency. Whether you are plowing, tilling, or transporting heavy loads, the Massey Ferguson 390 4WD is designed to meet your needs and exceed your expectations. This tractor is a model almost similar to the Massey Ferguson 385 4WD Tractor.
FAQs
The Massey Ferguson 390 4WD tractor is powered by a 90 horsepower Perkins diesel engine.
The tractor features a sliding spur transmission with 8 forward and 2 reverse gears.
The hydraulic system has a maximum lifting capacity of 2,145 kg.
The tractor is designed for high fuel efficiency, reducing operational costs and environmental impact.
The tractor is equipped with large front (12.4/11-24) and rear (18.4/15-30) tires for enhanced traction and stability.
Its 4-wheel drive capability, large tires, and robust build make it ideal for challenging terrains such as muddy and sandy conditions.
